interactive electronic whiteboard-2

High definition interactive whiteboard designed for conference and classroom.

TouchDisplays offers a future for education and office, with 10 points multi touch screen and HD display, it’s perfect for teaching, presentation and conference. This next generation whiteboard has precise touch capability and excellent colour reproduction and life-like images.









interactive electronic whiteboard-5











VERSATILE TOUCH TECHNOLOGIES



TouchDisplays concentrates on providing the right touch, whiteboard from 65 inch up to 98 inch, we offers Infrared(IR) multi touch and Projected Capacitive(PCAP) multi touch, to deliver the solutions most economical and efficient.















UHD RESOLUTION DISPLAY



Having excellent colour reproduction and life-like image are essential for large-screen displays, 4K resolution is how we make it. High brightness up to 1500 nits and anti-glare technology makes it sunlight readable, helping you use more freely both indoor or outdoor.

interactive electronic whiteboard-3









interactive electronic whiteboard-6













ALL IN ONE OPTIONS



With extremely powerful fanless RK3288/RK3399 and Intel i3/i5/i7 latest processors, our whiteboard could be compatible with Android or Windows. And multiple interfaces support all peripherals extensions.









APPLICATIONS

Interactive whiteboard is widely used in conference and classrooms, our white boards are compatible with relevant software and web cam, Bluetooth and WiFi are also available to meet the best performance.

Waterproof front panel with mark pen writable tempered glass makes friendly to children.

interactive electronic whiteboard-1










  • Eelmine:
  • Järgmine:

  • Mount raami specification_ 页面 _1

    推车 挂架 参数 3 推车 挂架 参数 2Mount raami specification_ 页面 _3Mount raami specification_ 页面 _4

    Mount raami specification_ 页面 _5

    mudel

    6501E-IOT

    Case / Bezel Värvus

    Must / Hõbedane / valge (Kohandatud)

    Ekraani suurus

    65 "

    Puutepaneel

    IR puutetundlik

    Touch reaktsiooniaeg

    16ms

    Touchcomputors Mõõdud

    1483 mm x 80,4 mm x 858 mm

    LCD Type

    TFT LCD (LED taustvalgus)

    Kasulik Screen Area

    1428,48 mm x 803,52 mm

    Kuvasuhe

    16: 9

    Optimaalne (emakeel) Resolutsioon

    1920 x 1080 (4K resolutsiooni valikuline)

    LCD paneel Pixel pitch

    0,248 x 0,744 mm

    LCD paneel Värvid

    1,07 värvid (8-bitine + FRC)

    LCD paneel heledus

    350 cd / m2 (kohandatud upto 1000-2000 cd / m2 vabatahtlik)

    LCD paneel Response Time

    6,5 ms

    LCD paneel kontrastsusmäär

    5000: 1

    Vaatenurk

    horisontaalne

    ± 89 ° või 178 ° kõigi

    (Tüüpiline, tsentrist)

    vertikaalne

    ± 89 ° või 178 ° kõigi

    monitor modul

    sisendi liides

    VGA(for computor display input)DVIHDMI(for another display input)

    Earphone out*1Audio in*1

    arvuti modul

    sisendi liides

    USB 2.0*4(USB 3.0*1 optional)PCI-E(4G SIM card, WIFI and Bluetooth optional)

    väljund liides

    Earphone*1Mic*1Com*3RJ45*1

    VGA (eest computor kuvariväljund) ja HDMI (teisele kuvariväljund)

    laiendada liides

    USB2.0*4Com*21*PLTSATA3.0

    ECM (Embed Arvuti Modul)

    ECM4:  Inteli® protsessor i3 5010U (kahetuumane 2.1GH, Fanless);

    ECM5:  Inteli® protsessor i5 5200U (kahetuumane 2,2 GHz / 2,7 GHz Turbo, Fanless);

    ECM6:  Inteli® protsessor i7 5500U (kahetuumane 2,4 / 3.0Ghz Turbo, Fanless);

    HDD: 500G(1TB optional) or SDD: 32G (kuni 128G valikuline);

    Mälu:  DDR3 4G(up to 16G);

    CPU Upgrade: I3-I7 series 6th  7 th  vabatahtlik

    Operation System:Win7Pos ready7Win8XPWinCEVistaLinux Ubuntu

    ECM9:  Cortex-A53 8 Core 1.5GHz; GPU : PowerVR G6110;

    Rom : 2G (kuni 4G vabatahtlik); Flash : 8G (kuni 32G vabatahtlik);

    Operation System: 5.1 or 6.0

    ECM10: Dual Cortex-A72 + Quad Cortex-A53 6 Core 2.0GHz; GPU : Mali-T860;

    Rom : 2G (kuni 4G vabatahtlik); Flash : 8G (kuni 32G vabatahtlik);

    Operation System: 7.0

    Elektritoite tüüp

    AC DC võimsus tellistest sisend: 90-240 VAC, 50/60 Hz

    Energiatarve: 90W

    temperatuur

    Operating: 0 ° C kuni 40 ° C; Storage -20 ° C kuni 60 ° C

    Niiskus (mittekondenseeruv)

    Operating: 20% -80%; Hoiustamine: 10% -90%

    Kohaletoimetamine Carton Mõõdud

    1600 x 240 x 1000 mm (2 PCS)

    Kaal (u.)

    Toote Tegelik: 41 kg (1 tk); Transpordi: 99 kg (2 PCS)

    garantii Monitor

    4 aastat (välja arvatud LCD paneel 1 aasta)

    Taustvalgustuse lambi eluiga: tüüpiline 30000 tundi poole heleduse

    ameti tunnustuse

    CE / FCC RoHS (UL GS valikuline)

    Paigaldusvalikud

    200mmx100mm VESA mount
